DVD Video
For video.
DVD-5(single sided) : Playing time up to 133 minutes.
DVD-9(dual layer) : Playing time up to 240 minutes.

DVD-ROM
For Data.
DVD-5(single sided) : Data capacity up to 4.7GB of data files.
DVD-9(dual layer) : Data capacity up to 8.5GB of data files.

Please note that playing time and data capacity are depended on compression ratio of encoding.

Acceptable master media for DVD Press

• DLT Tape
  TAPEIII or TAPE IV for DLT-2000. DDP2.00 recommended.

• DVD-R
  DVD-R for Authoring recommended.
  Basically, your acknowledgment for proof disc is needed before DVD mass production.
  If you need to apply copy protection or press to DVD-9(double layer), you have to prepare DLT tape for the master.

We need following additional information for your master media.

1. Information of copy protection
   • CSS (Contents Scramble System)
     Digital copy protection. If apply, master media has to be DLT tape with CSS flagging.
   • APS(Analog Protection System)
     Macrovision's analog copy protection. If apply, you have to conclude a license agreement with Macrovision.


2. Information of audio coding type
   Audio coding type from coding types such as AC-3(aka Dolby Digital), or LPCM(Linear Pulse Code Modulation).


3. Information of MPEG-2
   MPEG-2 is a video compression format of MPEG(Moving Picture Expert Group)standard.


4. Information of Drive name
   E.g. DLT4000, DLT8000


5. Total Time (only for DVD-Video)
   The information of total time is needed


6. Information of Apply or not apply copy protection
   • CSS (Contents Scramble System)
     - The digital copy protection only for DVD-Video.
     Only CSS-FLAG proceeded DLT tape is acceptable. DVD-R is incapable for CSS.
   • APS (Analog Protection System)
     - The analog copy protection only for DVD-Video.
     The conclusion of licensing agreement with Macrovision Corporation is necessary for applying.


7. Information of Region code
   The information of region code, which indicates playable region, is necessary for DVD-Video.
   Region code is following.
   Notice that if the master media is DVD-R, you cannot select any region code but 'ALL'.



Region 1	North America, Canada
Region 2	Europe, East Asia, Japan, South Africa
Region 3	Southeast Asia
Region 4	South America, Australia and the other countries around Australia
Region 5	Russia, East Europe, Central Asia, Africa
Region 6	China
All	no restriction



8. Sound Information
   The information for sound type is necessary, such as AC-3 (Dolby Digital), Linear PCM (Linear Pulse Code Modulation).



Disc Label Printing
Silk-screen printing (usually 1 or 2 colors) and offset printing are both available.
More details.

Package
DVD case, Jewel case, paper sleeve, and various kinds of packages are available.
More details.

We concluded following license contracts in connection with DVD-Video and DVD-ROM manufacturing.

• DVD Player & Disc Patent License
  Contracts are consist of 4companies, and 6 companies and 1 company(11 companies in all).
• Dolby Digital (AC-3) Technology License
• MPEG-2 Patent Portfolio License
• DVD Format/Logo License
• CSS Technology License
• Analog Copy Protection System License

To prevent friction in market, we have been certified by Class A laboratory of DVD Forum and observe it for our dvd manufacturing.

DVD Forum Official Website : http://www.dvdforum.org/
